UW- value ≤ 0.9

An uncompromising system for elite real estate, fully compliant with strict Passivhaus standards. The seven-chamber 88 mm thick profile structure provides record thermal insulation, turning the entrance door into an impenetrable barrier against summer heat. The static rigidity of the profile allows designing massive designer doors of increased height without risk of deformation under their own weight.

Three seal circuits create an isolated "dry chamber" for hardware, protecting mechanisms from corrosion, dust, and sea salt. Thanks to the ability to install extra-thick armored panels and glass, the 88 Puerta system guarantees maximum privacy and silence in the home. This is an investment in durability and comfort of the highest level.

Technical Specifications

Details

An elite premium-class door system designed for passive houses. Offers maximum thermal and sound insulation performance.

Energy efficiency
A++
Material
PVC (Ultra-Premium)
Profile depth
88 mm
Profile chambers
7 chambers
Seals
3 seals
Glazing unit
up to 56 mm
Thermal protection (Uw)
≤ 0.9 W/(m²·K)
Sound insulation
≈ 48 Rw(dB)

Structural system parameters:

  • Mounting depth: 88 mm.
  • Material: Premium Greenline PVC, certified by the Passivhaus Institute for energy-efficient construction.
  • Profile construction: 7-chamber system with three seal circuits (MD central seal).
  • Reinforcement: Massive steel reinforcement of maximum cross-section; welded corner connectors for absolute torsional rigidity.
  • Opening type: Universal (inward/outward), compatible with automatic drives.
  • Threshold: Highly insulated threshold with thermal break and multi-stage protection against rain water.

Glazing and infill options:

  • Maximum infill thickness: up to 56 mm.
  • Infill types: Armored panels, triple-chamber acoustic glazing units, designer panels "flush" with the profile.

Maximum structure dimensions:

  • Maximum sash height: up to 2500 mm.
  • Maximum sash width: up to 1250 mm.
  • Innovations: Possibility of installing fully concealed hinges and concealed door closers.

Certified specifications:

  • Profile thermal insulation (Uf): up to 1.0 W/m²K.
  • Sound insulation (Rw): up to 48 dB.
  • Burglar resistance: Up to class RC3.
  • Air permeability: Class 4 (Highest).

Documentation

Kömmerling 88 Puerta Technical Specifications
Technical Specifications
PDF. 4.5Mb

Kömmerling 88 Puerta

An elite premium-class door system designed for passive houses. Offers maximum thermal and sound insulation performance.

Average market price:

For a standard entrance door (900 × 2100 mm) with a mid-range filling panel.

Calculate your door
Comfort Index
Heat insulation
9/10
Noise insulation
9/10

Compare with Similar Profiles

Alternative solutions from other manufacturers

UW- value ≤ 1.3
Kömmerling EuroFutur Puerta

Kömmerling EuroFutur Puerta

A classic 70 mm deep door system combining proven reliability and elegant design. The optimal solution for entrance groups in residential buildings and commercial premises.
Energy efficiency
B+
Material
PVC (Greenline)
Profile depth
70 mm
Profile chambers
5 chambers
Seals
2 seals
Glazing unit
up to 39 mm
Thermal protection (Uw)
≤ 1.3 W/(m²·K)
Sound insulation
≈ 40 Rw(dB)
More details
UW- value ≤ 0,79
Kömmerling 76 Puerta

Kömmerling 76 Puerta

A next-generation modern door system with 76 mm depth. Provides a balance between high energy efficiency and structural strength.
Energy efficiency
A
Material
PVC (Xtrem)
Profile depth
76 mm
Profile chambers
5 chambers
Seals
2 seals
Glazing unit
up to 50 mm
Thermal protection (Uw)
≤ 1 W/(m²·K)
Sound insulation
≈ 47 Rw(dB)
More details
UW- value ≤ 1.1
Kömmerling AluClip Puerta

Kömmerling AluClip Puerta

A hybrid door system combining the strength and RAL color palette of aluminum with superior PVC thermal insulation. Modern hi-tech aesthetics with eco-friendly efficiency.
Energy efficiency
A+
Material
PVC + Aluminum
Profile depth
83.5 mm
Profile chambers
5 chambers
Seals
2 seals
Glazing unit
up to 50 mm
Thermal protection (Uw)
≤ 1.1 W/(m²·K)
Sound insulation
≈ 44 Rw(dB)
More details
UW- value 1.3
Rehau Euro-Design 70 economical entrance door

Rehau Euro-Design 70 Door

Optimal 70 mm PVC entrance door with the best price-to-German-quality ratio. 5-chamber profile, glossy HDF surface and reliable security hardware.
Energy rating
A
Door Type
Standard 70mm
Profile Depth
70mm
Chambers
5 chambers
Panel Thickness
up to 41mm
Security
RC1 / RC2
Thermal protection
Uw ≤ 1.3 W/(m²·K)
Sound insulation
≈ 40 Rw(dB)
More details
UW- value 1.2
Rehau Brillant-Design Door

Rehau Brillant-Design 70 Door

Classic reliable 70mm PVC entrance door with high stability and elegant rounded design. Premium HDF surface finish for lasting aesthetic appeal.
Energy rating
A
Door type
Entrance door
Profile depth
70mm
Profile chambers
5 chambers
Panel thickness
up to 42mm
Security
up to RC2
Thermal protection
Uw ≤ 1.2 W/(m²·K)
Sound insulation
≈ 42 Rw(dB)
More details
UW- value 0.90
Technical cross-section of Rehau Synego 80mm profile: general view

Rehau Synego 80 Door

Energy-efficient 80mm door (Passivhaus standard). Up to 50% more heat retention, 46 dB sound insulation and RC3 break-in resistance.
Energy rating
A++
Door type
Entrance door
Profile depth
80mm
Profile chambers
7 chambers
Panel thickness
up to 51mm
Security
up to RC2
Thermal protection
Uw ≤ 0.90 W/(m²·K)
Sound insulation
≈ 46 Rw(dB)
More details

Side by side

Head to Head: Closest Competitors

How Kömmerling 88 Puerta stacks up against the closest matches from other brands.

SpecificationKömmerling 88 PuertaThis profileRehau Synego 80 DoorSchüco LivIng DoorVeka Softline 82 Door
BrandKömmerlingREHAUSchücoVEKA
MaterialPVCPVCPVCPVC
Profile depth88 mm80mm82mm82 mm
Chambers7 chambers7 chambers7 chambers7 chambers
Glass unit, maxup to 56 mmup to 51mmup to 52mmPanel / up to 52mm
Thermal (Uw)≤ 0.90.900,801.1
Sound (Rw, dB)≈ 48 Rw(dB)≈ 46 Rw(dB)≈45 Rw(dB)≈ 44 Rw(dB)

See all door profiles compared.

Open full comparison

Leave a Review

Customer Reviews

Find out what people are saying about it

0.0
Average rating
0 reviews
5 ★
0
4 ★
0
3 ★
0
2 ★
0
1 ★
0

No reviews yet. Be the first!

FAQs

Frequently Asked Questions about Kömmerling 88 Puerta

Why is the 88 series considered the safest?

The massive profile allows installation of armored panels and glazing units up to 56 mm, as well as RC3 class hardware that is virtually impossible to break through with hand tools.

Can I order a very tall entrance door?

Yes, the statics of the 88 system allow manufacturing sashes up to 2.5 meters high without risk of distortion or loss of sealing.

How does the door perform in hurricane winds?

The system is certified to the highest air and water permeability classes. Even at wind pressure equivalent to a storm, not a single drop of water will get inside.

What infill options are available for the 88 series?

You can choose exclusive door panels with ceramics, natural stone, or concealed glazing that are installed flush with the frame profile.

Can the door be integrated into a Smart Home system?

Yes, there is enough space inside the profile for concealed routing of electric lock cables, status sensors (open/closed), and biometric scanners.

Does the door thickness affect ease of passage?

Despite its massiveness, hinges with needle bearings ensure easy opening. The force required to open is minimal.
