Kömmerling 88 MD is the pinnacle of engineering thought in PVC systems. The 88 mm mounting depth and seven air chambers inside the profile allow for incredible thermal insulation performance. This window literally blocks external heat, maintaining the indoor microclimate even without active use of air conditioning.
The system is designed for installation of heavy triple-glazed units up to 56 mm thick. If your project requires Passivhaus certification or you simply want the best that exists in the glazing industry today — 88 MD has no competitors.
Technical Specifications
Maximum protection from heat and noise. The thickest and most powerful system for those who want to save as much as possible on air conditioning. Your home will have absolute silence, even if windows face a busy road.
Structural system parameters:
Glazing and infill options:
Maximum structure dimensions:
Certified specifications:
Maximum protection from heat and noise. The thickest and most powerful system for those who want to save as much as possible on air conditioning. Your home will have absolute silence, even if windows face a busy road.
For a standard 2-sash tilt-and-turn window (1200 × 1400 mm) with basic double-glazed unit.
Alternative solutions from other manufacturers
Side by side
How Kömmerling 88 MD stacks up against the closest matches from other brands.
| Specification | Kömmerling 88 MDThis profile | Rehau Geneo PHZ | Cortizo A 84 Passivhaus | Schüco LivIng 82 |
|---|---|---|---|---|
| Brand | Kömmerling | REHAU | Cortizo | Schüco |
| Material | PVC | PVC | PVC | PVC |
| Profile depth | 88 mm | 86mm | 84 mm | 82mm |
| Chambers | — | 6 chambers | — | 7 chambers |
| Glass unit, max | up to 56 mm | 53mm | up to 56 mm | up to 52mm |
| Thermal (Uw) | ≤ 0.7 | 0.73 | ≤ 0.66 | 0.8 |
| Sound (Rw, dB) | ≈ 50 Rw(dB) | ≈50 Rw(dB) | ≈ 48 Rw(dB) | ≈47 Rw(dB) |
See all window profiles compared.
Open full comparisonLeave a Review
Find out what people are saying about it
No reviews yet. Be the first!
FAQs
The certificate confirms that the 88 MD system is capable of maintaining heat or coolness inside the home with virtually no external sources (heating or air conditioning). For Spain, this means that even in the hottest weather, a comfortable microclimate will be maintained inside the home, and your electricity costs will be the lowest possible.
88 mm allows placing 7 independent air chambers and three seal circuits inside the profile. This thickness creates an insurmountable barrier to external temperature effects. It is the most massive and quiet system in the Kömmerling line, created for projects where no compromises in quality are allowed.
When using special soundproofing glazing units, the 88 MD system can reduce noise levels by 50 dB. This allows comfortable living even near a railway, airport, or busy highway. Sounds from the outside world virtually disappear completely, turning your home into a zone of absolute tranquility.
The mounting rebate allows installing infill up to 56 mm thick. You can order heavy-duty triple-chamber glazing units with two selective glasses and argon filling. This also allows using thick laminated protective glass (6+6 or 8+8 mm) for maximum security.
This is a flagship product where every detail is thought through: from improved statics allowing huge sash sizes to exclusive surface finishing options. 88 MD windows look massive, solid, and emphasize the high status of the property, significantly increasing its market value.
The 88 MD system is designed for an operational life of over 50 years. Thanks to the enormous strength reserve of the profile, reinforced armoring, and protected hardware, the window maintains its functionality and appearance for several generations. This is an investment that pays for itself with decades of impeccable service.
